| 廠家(產地) | 韓國錦湖 |
|---|---|
| 牌號 | GP-125EB |
| 加工級別 | 注塑級 |
| 銷售方式 | 品牌經銷 |
| 類型 | 標準料 |
產品參數
| 性能項目 | 試驗條件[狀態] | 測試方法 | 測試數據 | 數據單位 | |
| 基本性能 | 熔體流動速率 | 200℃,5kg | ASTM D-1238 | 5.5 | g/10min |
| 吸水率 | 24hr | ASTM D-570 | 0.030 | % | |
| 物理性能 | 比重 | ASTM D-792 | 1.04 | g/cm3 | |
| 模具收縮率 | ASTM D-955 | 0.30-0.60 | % | ||
| 機械性能 | 屈服拉伸強度 | ASTM D-638 | 53.8 | MPa | |
| 屈服伸長率 | ASTM D-638 | 2.0 | % | ||
| 彎曲模量 | ASTM D-790 | 3130 | MPa | ||
| 屈服彎曲強度 | ASTM D-790 | 97.9 | MPa | ||
| IZOD缺口沖擊強度 | 3.18mm | ASTM D-256 | 21.9 | J/m | |
| 洛氏硬度 | ASTM D-785 | 80 | M scale | ||
| 電氣性能 | 體積電阻率 | ASTM D-257 | 1.0×1016 | ohm.cm | |
| 介電強度 | ASTM D-149 | 21.7 | KV/mm | ||
| 介電常數 | 1×106Hz | ASTM D-150 | 2.500 | ||
| 熱性能 | 熱變形溫度 | 1.80MPa，未退火 | ASTM D-648 | 92.2 | ℃ |
| 維卡軟化點 | ASTM D-1525 | 107 | ℃ | ||
| 燃燒性 | 1.59mm | HB | UL 94 | ||
| 燃燒性 | 3.18mm | UL 94 | HB | ||
| 燃燒性 | 6.35mm | UL 94 | HB | ||
| RTI Str | 1.59mm | UL 746 | 50.0 | ℃ | |
| RTI Str | 3.18mm | UL 746 | 50.0 | ℃ | |
| RTI Str | 6.35mm | UL 746 | 50.0 | ℃ | |
| RTI Imp | 1.59mm | UL 746 | 50.0 | ℃ | |
| RTI Imp | 3.18mm | UL 746 | 50.0 | ℃ | |
| RTI Imp | 6.35mm | UL 746 | 50.0 | ℃ | |
| RTI Elec | 1.59mm | UL 746 | 50.0 | ℃ | |
| RTI Elec | 3.18mm | UL 746 | 50.0 | ℃ | |
| RTI Elec | 6.35mm | UL 746 | 50.0 | ℃ | |
