特性級別	抗紫外線,高抗沖
銷售方式	品牌經銷
類型	標準料
規格級別	注塑級
廠家(產地)	沙伯基礎創新塑料
牌號	XTPM405
加工級別	注塑級

東莞市東如信塑膠原料有限公司長期供應SABIC（沙伯基礎創新塑料） GELOY  ASA，ASA/PC，長期供應，柜貨訂購，原廠原裝，可開稅票，可送貨上門，可到倉庫看貨，可提供材質報告，物性表、MSDS、REACH、SGS、 出廠證明，外加技術指引等，歡迎來電洽談，電話：15818367582/18938556268，劉先生



GeloyXTPM405 簡介：

High flow PC/ASA with improved impact at room and low temperatures. Improved release. Excellent weatherability for outdoor unpainted or clearcoated applications. Injection Moldable with large color gamut.



GeloyXTPM405 物性表：

TYPICAL PROPERTIES(1)
MECHANICAL	Value	Unit	Standard
Tensile Stress, yield	490	kgf/cm?	ASTM D 638
Tensile Strain, break	90	%	ASTM D 638
Tensile Modulus, 5 mm/min	24400	kgf/cm?	ASTM D 638
Tensile Stress, yield, 50 mm/min	47	MPa	ISO 527
Tensile Stress, break, 50 mm/min	39	MPa	ISO 527
Tensile Strain, yield, 50 mm/min	3	%	ISO 527
Tensile Strain, break, 50 mm/min	55	%	ISO 527
Tensile Modulus, 1 mm/min	2400	MPa	ISO 527
Flexural Stress, yield, 2 mm/min	75	MPa	ISO 178
Flexural Modulus, 2 mm/min	2200	MPa	ISO 178
IMPACT	Value	Unit	Standard
Izod Impact, notched, 23°C	144	cm-kgf/cm	ASTM D 256
Izod Impact, notched, 0°C	13	cm-kgf/cm	ASTM D 256
Izod Impact, notched, -20°C	13	cm-kgf/cm	ASTM D 256
Instrumented Impact Total Energy, 23°C	407	cm-kgf	ASTM D 3763
Instrumented Impact Total Energy, -30°C	112	cm-kgf	ASTM D 3763
Izod Impact, notched 80*10*4 +23°C	65	kJ/m?	ISO 180/1A
Izod Impact, notched 80*10*4 -30°C	10	kJ/m?	ISO 180/1A
Charpy Impact, notched, 23°C	65	kJ/m?	ISO 179/2C
THERMAL	Value	Unit	Standard
Vicat Softening Temp, Rate B/50	103	°C	ISO 306
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm	88	°C	ISO 75/Af
PHYSICAL	Value	Unit	Standard
Melt Flow Rate, 260°C/5.0 kgf	30	g/10 min	ASTM D 1238
Density	1.12	g/cm?	ISO 1183
Melt Flow Rate, 220°C/10.0 kg	14	g/10 min	ISO 1133
Melt Viscosity, 260°C, 1500 sec-1	120	Pa-s	ISO 11443

Source GMD, last updated:2010/11/18

GeloyXTPM405 加工指引：

Parameter
Injection Molding	Value	Unit
Drying Temperature	90 - 100	°C
Drying Time	3 - 4	hrs
Drying Time (Cumulative)	8	hrs
Maximum Moisture Content	0.04	%
Melt Temperature	255 - 270	°C
Nozzle Temperature	240 - 255	°C
Front - Zone 3 Temperature	245 - 260	°C
Middle - Zone 2 Temperature	240 - 255	°C
Rear - Zone 1 Temperature	230 - 250	°C
Mold Temperature	55 - 70	°C
Back Pressure	0.3 - 1	MPa
Screw Speed	30 - 80	rpm
Shot to Cylinder Size	40 - 80	%
Vent Depth	0.038 - 0.076	mm
