| 廠家(產地) | 伊斯曼化學 |
|---|---|
| 銷售方式 | 品牌經銷 |
| 訂購 | 2 region-detail-feature 已選0千克/0.00元 廠家(產地) |
| 類型 | 標準料 |
| 牌號 | TX2001 |
| 用途級別 | 食品級 |
| |||
| 產品說明 | ||||
| Eastman Tritan™ TX2001 is an amorphous copolyester with excellent appearance and clarity. Tritan™ TX2001 contains a mold release derived from vegetable based sources. Its most outstanding features are excellent toughness, hydrolytic stability, and heat and chemical resistance. This new-generation copolyester can also be molded into various applications without incorporating high levels of residual stress. Combined with Tritan™ copolyester's outstanding chemical resistance and hydrolytic stability, these features give molded products enhanced durability in the dishwasher environment, which can expose products to high heat, humidity, and aggressive cleaning agents. Tritan™ TX2001 copolyester may be used in repeated use food contact articles under United States Food and Drug Administration (FDA) regulations. Tritan™ TX2001 copolyester is certified to NSF/ANSI Standard 51 for Food Equipment Materials and is also certified to NSF/ANSI Standard 61 - Drinking Water System Components-Health Effects. | ||||
| 添加劑 | 脫模 | |||
| 性能特點 |
| |||
| 用途 |
| |||
| 機構評級 |
| |||
| 加工方法 | 注射成型 | |||
| 物理性能 | 額定值 | 單位制 | 測試方法 |
| 比重 | 1.17 | g/cm³ | ASTM D792 |
| 收縮率 - 流動 | 0.50 到 0.70 | % | ASTM D955 |
| 硬度 | 額定值 | 單位制 | 測試方法 |
| 洛氏硬度 (R 計秤, 23°C) | 115 | ASTM D785 |
| 機械性能 | 額定值 | 單位制 | 測試方法 |
| 拉伸模量 | |||
| 23°C | 1590 | MPa | ASTM D638 |
| 23°C | 1620 | MPa | ISO 527-2 |
| 抗張強度 | |||
| 屈服, 23°C | 44.0 | MPa | ASTM D638 |
| 屈服, 23°C | 45.0 | MPa | ISO 527-2 |
| 斷裂, 23°C | 53.0 | MPa | ASTM D638 |
| 斷裂, 23°C | 49.0 | MPa | ISO 527-2 |
| 伸長率 | |||
| 屈服, 23°C | 7.0 | % | ASTM D638, ISO 527-2 |
| 斷裂, 23°C | 140 | % | ASTM D638 |
| 斷裂, 23°C | 130 | % | ISO 527-2 |
| 彎曲模量 | |||
| 23°C | 1590 | MPa | ASTM D790 |
| 23°C | 1530 | MPa | ISO 178 |
| 彎曲強度 (屈服, 23°C) | 66.0 | MPa | ASTM D790 |
| 沖擊性能 | 額定值 | 單位制 | 測試方法 |
| 懸壁梁缺口沖擊強度 | |||
| 23°C | 650 | J/m | ASTM D256 |
| -40°C | 14 | kJ/m² | ISO 180 |
| 23°C | 66 | kJ/m² | ISO 180 |
| 無缺口懸臂梁沖擊 (23°C) | 無斷裂 | ASTM D4812 |
| 熱性能 | 額定值 | 單位制 | 測試方法 |
| 熱變形溫度 | ASTM D648 | ||
| 0.45 MPa, 未退火 | 109 | °C | |
| 1.8 MPa, 未退火 | 92.0 | °C |
| 光學性能 | 額定值 | 單位制 | 測試方法 |
| 透射率 (總計) | 92.0 | % | ASTM D1003 |
| 霧度 | < 1.0 | % | ASTM D1003 |
| 注射 | 額定值 | 單位制 | |
| 干燥溫度 | 88.0 | °C | |
| 干燥時間 | 4.0 到 6.0 | hr | |
| 加工（熔體）溫度 | 260 到 282 | °C | |
| 模具溫度 | 38.0 到 66.0 | °C |
