>>>單面導通碳膜系列產品選用納米級超導碳黑、碳納米管及石墨烯為原料，采用特殊壓合工藝成膜后再與基材進行貼合。以上工藝所制成的復合碳膜，面阻均勻穩定，材質整體均一耐彎折，通過后期客戶的封裝工藝，可以實現耐酸、耐油、耐熱、耐寒、阻燃及抗氧化，使用壽命可達20年以上。不導電面具有良好的印刷性能，可根據需要印刷各種標示圖案，滿足個性化的LOGO需求。

>>> The series of single-side conductive carbon films are made of nano-superconducting carbon black, carbon nanotubes and graphene, and then bonded to the substrate by a special pressing process. The composite carbon film prepared by the above process has uniform and stable surface resistance and uniformly bending-resistant material as a whole. Through the packaging process of the later customers, the composite carbon film can be acid-resistant, oil-resistant, heat-resistant, cold-resistant, flame-retardant and oxidation-resistant, and has a service life of more than 20 years. Non-conductive surface has good printing performance, can print a variety of logo patterns according to needs, to meet the personalized LOGO requirements.

應用于**、電磁屏蔽、電熱等產品。

Used in physiotherapy electrodes, electromagnetic shielding, electric heating and other products.

主要技術參數如下：

The main technical parameters are as follows:

●常規方阻General square resistance：10~100,000Ω/□

●厚度Thickness：20~400μm

●寬度Width：5~1500mm

●長度不限Unlimited length

●常規使用溫度Conventional service temperature：-20~160℃

●極端耐溫性Extreme temperature resistance：-40~220℃
