吹膜厚度	0.003-0.10
最大吹膜寬度	600
種類	吹膜機組
適用原料	LDPE、HDPE、LLDPE
生產能力	30
品牌	龍堯
型號	SJM-Z35×30-700



用途：用于吹制低密度聚乙烯（LDPE），高密度聚乙烯（HDPE及線型低密度聚乙烯（LLDPE）的塑料薄膜，廣泛用于水果、食品、服裝、紡織品、日用品等民用和工業用品的包裝。
特點：1.擠出機適用范圍廣，可加工LDPE、LLDPE、mLLDPEPP等原料。 2.控制柜元器件選擇更可靠合理，操作方便。
3.整機結構緊湊，零部件加工和裝配工藝進行了較大的改進和完善，提高了加工精度和裝配質量。
4.可按用戶需要配備旋轉機頭。
5.卷取型式可根據用其所長戶需要配制。.APPLICATION   These  lines  can produce kinds of plastics film of LDPE,HDPE and LLDPE, which are widey used in the packing of fruit, food, clothing,textiles,croceries for daily use industrial products,and ground film.FEATURES 1.      Extruder barrel and screw are made of high quality alloy steel, nitrided and manufactured by precision maching.2.      Ttey are provided with very high surface to resist corrosion and abrasion. The screw L/D ratio of extruder is larger, plastication capacity of extruder is high. The temperature is well distributed. Drovwing to low by hand shaking, All these functions improve use property of plastics film.

技術規范 SPECIFICATIONS

型號 model     sjm-z35*30-700 螺桿直徑　 screw diameter mm   Φ35 螺桿長徑比 screw ratio     30：1 螺桿轉速 screw speed r/min   17-170 主電機功率 rmain motor powe kw   11 **大產量 max.extrusion output kg/h   LDPE-30　HDPE-20 制品厚度 film thickness mm   0.003-0.10 制品**大折幅寬度 max.fold width of film mm   600 ?？谝?guī)格 range of die mm   Φ60Φ80Φ120 電氣總功率 electric totoal capacity kw   25 外形尺寸 overall dimensions m   5×1.9×2.7 機組重量 weight of line kg   2250
